MC3400 Series Mobile Computer
Product Category : Mobile ComputersBuilt for Tough Environments and Modern Workflows—Now with More Power, Advanced Scanning, Wi-Fi 6E, and 5G.
Introducing the latest MC3400 and MC3450 mobile computers from the MC3000 Series. Available in straight shooter and gun forms, these devices offer 2.5x more processing power for demanding apps. Stay connected with Wi-Fi 6E, 5G, and Private 5G. Enhance security with biometric facial recognition. Enjoy easier data entry with an improved keypad and increased reliability with a rugged design. Leverage Zebra DNA for enhanced capabilities and rely on Zebra’s services for seamless device management.
Specifications
Physical Characteristics
| Dimensions | Straight Shooter: 8.2 in L x 2.9 in W x 1.5 in H (208.5mm L x 73.5mm W x 37.1mm H) Gun: 8.2 in L x 2.9 in W x 6.5 in H (208.5mm L x 73.5mm W x 165.3mm H) |
| Weight | Straight Shooter: 15.6 oz (442g) Gun: 18.6 oz (528g) |
| Display | 4 in WVGA (800 x 480), color display, Standard: 350 NITS (typical), Expanded/Full: 600 NITS (typical) |
| Imager Window | Corning® Gorilla® Glass |
| Touch Panel | Dual mode capacitive touch with finger, gloved finger or stylus input (conductive stylus sold separately); Corning Gorilla Glass optically bonded |
| Power | Standard Rechargeable Li-Ion: 3.6V, 7000mAh (25.20 Wh); Optional BLE Battery Li-Ion 3.6V, 7000mAh (25.2 Wh); Hot swap battery backup with temporary session persistence |
| Expansion Slot | MicroSD supports up to 2 TB |
| SIM | MC3450 only: 1 nano SIM; 1 eSIM |
| Network Connections | MC3400/MC3450: WLAN, WPAN (Bluetooth), USB 2.0 High Speed (host and client); MC3450 only: WWAN 5G, data only |
| Notifications | Audible tone; multi-color LEDs (2); haptic feedback |
| Keypad | Numeric (29 key), Function Numeric (38 key), Alpha Numeric (47 key) |
| Voice and Audio | Speaker, microphone, Push-to-Talk (PTT Voice; internal speaker, Bluetooth wireless headset support, USB-C headset) |
| Buttons | Trigger scan button (Gun); Keypad scan button, Side Scan Keys (Straight Shooter) |
| Interface Ports | USB 2.0 (Bottom pogo connector and side USB-C connector) — High Speed (Host and Client) |
Performance Characteristics
| CPU | Qualcomm® 4490 octa-core, 2.4 GHz |
| Operating System | Android; for supported Android versions, |
| Memory | Standard: 4 GB RAM/64 GB Flash; Expanded: 6 GB RAM/64 GB Flash; Full: 6 GB RAM/128 GB Flash |
| Security | FIPS 140-2 Validated; Common Criteria certified; Supports Secure Boot and Verified Boot |
User Environment
| Operating Temperature | -4F to +122F (-20C to +50C) |
| Storage Temperature | -40F to +158F (-40C to +70C) |
| Humidity | 5% to 95% non-condensing |
| Drop Specification | Per MIL-STD 810H: 8 ft (2.4m)6 to concrete at (+23C/+73F); 6 ft (1.8m) to concrete across temperature (-20C to +50C/-4F to +122F) exceeding MIL-STD-810H |
| Tumble Specification | 4,000 3.3 ft (1m) tumbles; meets or exceeds IEC tumble specification |
| Sealing | Dual IP65 and 67 rating with battery per applicable IEC sealing specifications |
| Vibration | 4 g’s PK Sine (5 Hz to 2 kHz); 0.04g 2/Hz Random (20 Hz to 2 kHz); 60 minute duration per axis, 3 axis |
| Electrostatic Discharge (ESD) | +/- 15 kV air discharge; +/- 8 kV direct discharge; +/- 8 kV indirect discharge |
Interactive Sensor Technology (IST)
| Light Sensor | Automatically adjusts display backlight brightness (Expanded and Full) |
| Magnetometer | MC3450 only: eCompass automatically detects direction and orientation |
| Motion Sensor | 3-axis accelerometer with MEMS Gyro |
General Certifications
| TAA compliant; ARCore Google7 pending |
Data Capture
| Scanning | SE58 1D/2D Extended Range Scan Engine with IntelliFocus™ technology; SE55 Advanced Range Scan Engine with IntelliFocus™ technology; SE4770 1D/2D Scan Engine; SE4710 1D/2D Scan Engine |
| Camera | Front: 5 MP; Rear: 13 MP autofocus; flash LED generates balanced white light; supports Torch mode + HDR |
| NFC | NFC ISO 14443 Type A and B; Mifare, FeliCa and ISO 15693 cards, NFC Forum tags 2,3,4,5 |
Wireless WAN Data Communications (MC3450 Only)
| Radio Frequency Band | 3G: NA: B2/4/5; ROW: 1/2/4/5/8; China+Japan: B1/5/6/8; 4G: NA: B2/4/5/7/8/12/13/14/17/25/26/29/30/38/41/48/66/71; ROW: B1/2/3/4/5/7/8/12/17/18/20/26/28/38/39/40/41/42/43/66/71 China+Japan: B1/3/5/7/8/28/34/38/39/40/41/42; 5G FR1: NA: n2/5/7/8/12/13/14/25/26/29/30/38/41/48/66/71/77/78; ROW: n1/2/3/5/7/8/12/18/20/26/28/38/40/41/66/71/77/78; China+Japan: n1/3/5/7/8/28/38/40/41/77/78/79 Supports private networking (LTE/5G) Note: Actual band support may vary by country or carrier, contact Zebra Tech Support for more details. |
| GPS | MC3450 only: GPS, GLONASS, Galileo, QZSS Dual-Band GNSS — Concurrent L1/G1/E1 (GPS/QZSS, GLO, GAL) + L5/E5a/BDSB2a (GPS/QZSS, GAL) a-GPS Supports XTRA |
| Multimedia | Wi-Fi Multimedia™ (WMM) and WMM-PS; including TSPEC |
| VOIP Communications | Supports Workcloud CommunicationTM PTT Express and Workcloud Communication PTT Pro |
Wireless LAN
| Radio | IEEE 802.11 a/b/g/n/ac/ax/d/h/i/r/k/v/w/mc; 2x2 MU-MIMO; Tri-band (2.4 GHz, 5 GHz, 6 GHz); Wi-Fi CERTIFIED 6™ (Wi-Fi 6E); Dual Band Simultaneous; IPv4, IPv6 |
| Data Rates | 2.4 GHz: 802.11b/g/n/ax — 20 MHz - up to 286.8 Mbps; 5 GHz: 802.11a/n/ac/ax — 20 MHz, 40 MHz, 80 MHz, 160 MHz - up to 2402 Mbps; 6 GHz: 802.11ax— 20 MHz, 40 MHz, 80 MHz, 160MHz - up to 2402 Mbps |
| Operating Channels | Channel 1-13 (2401-2483 MHz): 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13; Channel 36-165 (5150-5850 MHz): 36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 124, 128, 132, 136, 140, 144, 149, 153, 157, 161, 165; Channel 1-233 (5925-7125 MHz); Channel Bandwidth: 20, 40, 80, 160 MHz; Actual operating channels/frequencies and bandwidths depend on regulatory rules and certification agency. |
| Security and Encryption | WPA3 Enterprise 192-bit mode, GCMP256 — EAP-TLS; WPA3 Enterprise, AES-CCMP-128 — EAP-TTLS (PAP, MSCHAP, MSCHAPv2), EAP-TLS, PEAPv0-MSCHAPv2, PEAPv1-EAP-GTC, LEAP, EAP-PWD; WPA3 Personal (SAE), AES-CCMP-128; WPA/WPA2 Enterprise, TKIP and AES-CCMP-128; WPA/WPA2 Personal (PSK), TKIP and AES-CCMP-128; Enhanced Open (OWE), AES-CCMP-128; WEP 40 bit and 104 bit; WAN device only: EAP-SIM, EAP-AKA, EAP-AKA Prime |
| Certifications | Wi-Fi Alliance Certifications: Wi-Fi CERTIFIED n; Wi-Fi CERTIFIED ac; Wi-Fi CERTIFIED 6 (Wi-Fi 6E); WPA2-Personal; WPA2-Enterprise; WPA3-Personal WPA3-Enterprise (includes 192-bit mode); Protected Management Frames: Wi-Fi Enhanced Open; WMM (Wi-Fi Multimedia); WMM-Power Save; WMM-Admission Control; Voice-Enterprise: Wi-Fi Direct; Wi-Fi Agile Multiband; Wi-Fi QoS Management; Wi-Fi Optimized Connectivity Passpoint |
| Fast Roam | 802.11r Fast BSS Transition; PMK Caching; Cisco CCKM; OKC |
Wireless PAN
| Bluetooth | Class 1 and Class 2 configurable; Bluetooth v5.3 and Secondary BLE for beaconing within BLE battery |
Warranty
| Subject to terms of Zebra’s hardware warranty statement, the MC3400/MC3450 is warranted against defects in workmanship and materials for a period of 1 (one) year from the date of shipment. For complete warranty statement, please visit: www.zebra.com/warranty |
Environmental Compliance
| RoHS Directive 2011/65/EU RoHS Amendment (EU) 2015/863 (EN IEC 63000:2018 Standard); For a complete list of product and materials compliance, please visit www.zebra.com/environment |
Footnotes
1. Standard Gun, Expanded and Full Straight Shooter configuration support 12-month subscriptions. The Gun Expanded and Full configurations support subscription for the life of the device.
2. Requires the purchase of the optional BLE battery and Device Tracker licenses.
3. Requires a Workcloud Communication license.
4. Next-day delivery dependent upon region and time request is received.
5. LifeGuard for Android is included with every Zebra OneCare Support agreement. Some features, such as Over-the-Air remote updates and update status are available through a supported EMM.
6. Applicable to WLAN Gun configuration only.
7. ARCore certification will be available Q2 2025.
Zebra DNA
| The Zebra DNA software suite makes your devices more powerful and easier to manage, with tools that ensure top performance, simple setup, and strong security. Zebra DNA for Mobile Computers is available on Android only Features may vary by model and a Support Contract may be required. |
